TRH-3351 air quality indicator, CO2, large digital Temperature and humidity monitor Product ID: TRH-3351
Large Digital Temperature and Humidity Displays
TRH-3351 Multi monitor is a cost-effective, air quality indicator, the large single digit LED display with three most critical parameters of indoor air quality, the current CO2 concentration, the ambient temperature and the relative humidity.
CO2-----CO2 concentration indicates the amount of fresh air ventilation being introduced to a space
Relative humidity----The relative humidity in air indicates the amount of moisture
Ambient temperature----The suitable ambient temperature brings the comfortable space.
Large Digital temperature and humidity displays
CO2 & Temperature & RH Specification:
- CO2 Measurement Range: 0-3,000 ppm
- Display Resolution: 1ppm at 0~1,000ppm; 5ppm at 1,001~2,000ppm; 10ppm at 2,001~3,000ppm
- Accuracy 0~2,000ppm: ±70 ppm or ±5% of reading, whichever is greater; over 2000ppm: +/-7% Repeatability ±20 ppm
- Temperature Dependence Typ. ±0.2% of reading per °C or ±2 ppm per °C, whichever is greater, referenced to 25°C
- Pressure Dependence 0.13% of reading per mm Hg
- Response Time About 2min for 63% of step change
- Warm-Up Time <60 seconds at 22°C Temperature
- Temperature Range 0°C to 40°C (32°F to 104°F) display
- Display Resolution 0.1°C (0.1°F(when temperature display is within 100°F)
- Display Options °C/°F
- Accuracy ±1°C(±2°F)
- Response Time 20-30 minutes (case must equalize with environment)
- RH Measurement Range 20%-90%
- RH Display Resolution 1%
- RH Accuracy ±5%RH@23°C
- Response time <5 min for 63% of step changeOperating & Storage condition
- Operating Temperature 0°C to 40°C (32°F to 104°F)
- Humidity Range 0 ~ 95% RH non-condensing
- Storage Temperature -20°C to 60°C( -4°F to 140°F)
- Power Supply Universal 100~240VAC, 50/60Hz , External Power Brick(included in package)
- Power Consumption 11 Watts (Max.)
