CL-326A Digtal Thermometer with calibrator, temperature calibrator
-T1, T2 dual input and T1-T2 function
- 11 types of thermocouple temperature measurement and calibration, K/J/T/E/R/S/N/L/U/B/C type thermocouple wire
and mV selection
- Maximum and minimum display, average, and reading retention function
- Users can choose Celsius or Fahrenheit temperature unit display
- Automatic shift 0.1°/1°
- Automatic shutdown function
- Dual input and output
- CE certified
SPECIFICATIONS
Thermocouple(Resolution) Measuring Range
K-TYPE(0.1°) -200°C to 1372°C or -328°F to2501°F
J-TYPE(0.1°) -210°C to 1200°C or -346°F to 2192°F
T-TYPE(0.1°) -250°C to 400°C or -418°F to 752°F
E-TYPE(0.1°) -250°C to 1000°C or -418°F to 1832°F
R-TYPE(1°) 0°C to 1767°C or 32°F to 3212°F
S-TYPE(1°) 0°C to 1767°C or 32°F to 3212°F
N-TYPE(0.1°) -200°C to 1300°C or -328°F to 2372°F
L-TYPE(0.1°) -200°C to 900°C or -328°F to 1652°F
U-TYPE(0.1°) -200°C to 600°C or -328°F to 1112°F
B-TYPE(1°) 600°C to 1820°C or 1112°F to 3308°F
C-TYPE(1°) 0°C to 2316°C or 32°F to 4200°F
According to temperature standard ITS-90.
Accuracy:
K/J/T/E/L/U-TYPE
±(0.05% rdg + 0.5°C) -50°C to 1372°C
±(0.05% rdg + 1.0°C) -50°C to -250°C
±(0.05% rdg + 1.0°F) -58°F to 2501°F
±(0.05% rdg + 2.0°F) -58°F to -346°F
N-TYPE
±(0.05% rdg + 1.0°C) -50°C to 0°C
±(0.05% rdg + 0.5°C) 0°C to 1300°C
±(0.05% rdg + 2.0°F) -58°F to 32°F
±(0.05% rdg + 1.0°F) 32°F to 2372°F
R/S/B/C-TYPE
±(0.05% rdg + 2°C) 0°C to 1767°C
±(0.05% rdg + 4°F) 32°F to 3212°F
Thermocouple Simulate Range
Resolution: 0.1° (1° for R/S/B/C-TYPE)
Accuracy: ±(0.3°C+10uV)
Accuracy:
Accuracy is specified for operating temperatures over the range
of18°C to 28°C(64°F to 82°F), for 1 year, not including
thermocouple error.
mV Range
Range: -25.00mV to 75.00mV
Resolution: 10uV
Accuracy: ±(0.025%+1dgt)
Temperature Coefficient:
0.1 times the applicable accuracy specification per °C from 0°C to
18°C and 28°C to 50°C (32°F to 64°F and 82°F to 122°F).
ENVIRONMENTAL
Ambient Operating Ranges:
0°C to 50°C (32°F to 122°F) <80% R.H.
Storage Temperature:
-20°C to 60°C (-4°F to 140°F) <70% R.H.
CL-327A Process Calibrator
The NEW Tecpel® CL-327A is a battery-powered, hand-held process calibrator that allows process technicians to simulate and source variables signals. Output signals including DC voltage, DC current, ohms, analog transmitters, thermocouple, RTD, frequency, pulse, Switch On-OFF, are widely used in measurement and calibration for industrial field and laboratory application, it is one of necessary tools used to test and calibrate industrial automation systems and instruments. Get your job done fast and get it done precisely at affordable price. Your right choice!
Process Calibrator CL-327A
general characteristics:
1, The basic accuracy of the output of up to 0.02%, the output is displayed as 6 digit
2, The output functions: DC voltage, DC current, ohms, analog transmitters, thermocouple, RTD, frequency, pulse, Switch On-OFF
3, The DC current output, can provide 25 percent and 100 percent of manual stepping, automatic step and auto ramp output function
4, The thermocouple output, can provide high-precision automatic cold junction compensation, ℃ or ℉ temperature display
5, Outside with high-precision temperature probe, accuracy: ± 0.2 ℃
6, Large-screen LCD display multiple data can be displayed simultaneously: DC current and % values, thermocouples, temperature values of thermal resistance and the corresponding indexing values, etc.
7, The operating performance is superior keyboard configuration, set the value corresponding to the output bit setting change keys and LCD display.
*Working temperature and humidity
0 to 50ºC, ≤80% RH non-condensing
40 to 50ºC, ≤70% RH
*Storage temperature and humidity
-25 To 60ºC, ≤90% RH non-condensing
*Display and backlight
* Segment LCD dual display
* White LED backlight
*power supply
* 4 x 1.5V AAA alkaline batteries
* Automatic shutdown: can set auto-off time from 0 to 60 minutes
*Size and Weight
205 × 95 × 42 (mm), approximately 500g
CL-325 Process Calibrator 4-20mA
1. 4-20mA (1K Ohm load, 24V Loop Supply)
2. 0-100.00mV,0-1.000V, 0-12.000V
3. K, J, E, T Thermocouple (°C and °F)
4. Frequency 1-62500 Hz
5. 0.025% Basic Accuracy
6. Easy Key-pad Operation
7. Easy Step and Auto Ramp Functions
8. 0-20mA, 0-24mA selectable
9. 0-100% Input (mA, mV, V )
10. Beeper warning when output is open (mA) or short (mV,V)
The model CL-327 is discontinued and replaced by CL-327A
process calibrator
CL-420B Process Calibrator 4-20mA
The CL-420B Programmable Calibrator can measure loop current, voltage, and output current (current limiting).
It can calibrate signal receivers, digital displays, and industrial sensors.
Suitable for engineers to repair sensing equipment and test sensors.
DSL-336A Sound Level Calibrator
By many regulations, sound level meters need to verify their accuracy before and after measurements. Our sound calibrator series are designed to fulfill this customer needs. These calibrators provide different sound level at different frequencies to fit different regulations and they are perfect for periodical check on their sound level meters.
Features:
94dB and 114dB Sound Calibrator at 1kHz.
Accurate and Simple to Use.
Fits 1 inch and 1/2 inch Microphones.
Low battery indicator.
IEC 60942(2003) Class 2,Ans1.40-1984
Sound level meter, Sound level calibrator, LED display Video
