Insulation Resistance Tester
Brand
UNI-T
|
Model
UT511
|
🇨🇳 China
The UT511 offers multiple test voltage options, catering to a variety of applications and measurement needs. It is equipped with data storage and auto shutdown features, and can measure Polarization Index (PI) and Dielectric Absorption Ratio (DAR).
Price
NT$ 3,600
Out of Stock
Views: 2
Description
The UNI-T UT511 is a testing instrument designed for measuring insulation resistance of large transformers, generators, and high-voltage equipment. It offers multiple testing voltage options and a wide measurement range, making it ideal for professional electricians.
UT-511 High Insulation Resistance Meter 0.1MΩ ~ 10 G Ω, 100, 250, 500, 1000V
UT-512 High Insulation Resistance Meter 0.5MΩ ~ 100 G Ω, 500, 1000, 1500, 2500V
UT-513 high insulation resistance meter 0.5MΩ ~ 1000 G Ω, 500, 1000, 2500, 5000V
Specifications
- Test Voltage Options100V, 250V, 500V, 1000V
- Insulation Resistance0.1MΩ to 10GΩ ±(3%+5)
- DC Voltageup to 1000V ±(2%+3)
- AC Voltageup to 750V (50/60Hz) ±(2%+3)
- Low Resistance Measurement0.1Ω to 999.9Ω ±(1%+3)
- Short Circuit Currentless than 2mA
Features
- Auto RangeYes
- Data Logging18 sets of measurements
- Auto Power OffYes
- PI and DAR MeasurementYes
- Test Time Settingup to 30 minutes
- Comparison FunctionYes
- BacklightYes
- Overrange and High/Low Voltage WarningYes
- Low Battery IndicatorYes
- Max Display9999 digits
Attributes
- Power Supply8 x 1.5V batteries (R14)
- Dimensions123 x 58 mm
- Body ColorIron Gray
- WeightApproximately 2 kg
- Body Dimensions202 x 155 x 94 mm
- AccessoryPower Adapter (extra purchase required)
