Insulation Resistance Tester
Brand
UNI-T
|
Model
UT-512
|
🇨🇳 China
• Low and high resistance measurement modes
• High resistance mode offers selectable output voltages of 500V, 1,000V, 1,500V, and 2,500V
• USB data transmission
• Records up to 18 data points
• Analog bar display with 30 segments
• Timer settings up to 15 minutes
Price
NT$ 4,515
Out of Stock
Views: 664
Description
The UT-512 Insulation Resistance Tester allows for quick detection of insulation capabilities in electromechanical equipment, particularly suitable for large transformers, current transformers, generators, high-voltage motors, cables, and surge arresters. It features insulation resistance testing with PI (Polarization Index) and DAR (Dielectric Absorption Ratio) functions, effectively recording and analyzing data to determine the condition of insulation, ensuring safe operation of equipment.
Specifications
- Short Circuit Currentless than 1.8mA
- Test Voltage1M~5G Ω ±(3%+5)
- 1,500V5M~20G Ω ±(3%+5)
- Insulation Range10M~100G Ω ±(3%+5)
- DC Voltage600 V ±(2%+5)
- AC Voltage600 V ±(2%+5)
- Output Voltage0~20%
Features
- Data TransmissionUSB
- Data Logging18 records
- Analog Bar Graph30div
- Timer Setting15min
- SpecificationYes
- High Impedance ModeYes
- Output Voltage500V / 1,000V / 1,500V / 2,500V
Attributes
- Operating Temperature0~40°C / lower than 70%RH without dew。
- Storage Temperature-10~60 °C / lower than 80%RH without dew。
- Altitude LimitLower than 1,000 meters
- Power SupplyDC 1.5V Battery (LR14) x 8
- Dimensions202 x 155 x 94 mm
- WeightApprox. 1,800 g
- AccessoriesBattery, Carrying Case, CD, Alligator clip test lead, Manual
