32V/6A DC Power Supply
Brand
GWINSTEK
|
Model
GPE-3323
• Single channel output with max voltage of 32V and max current of 6A
• High setting and readback resolution of 10mV/1mA
• Large LCD display for easy operation
• Intelligent temperature-controlled fan for noise reduction
• Suitable for electronics industry and research laboratories
Out of Stock
Views: 58
Description
The GPE-3323 DC power supply is part of the GPE series by GW Instek, designed to meet the needs of the electronics industry and laboratories. It features a single channel output with a maximum voltage of 32V and a maximum current of 6A, providing high-resolution settings and readbacks (10mV/1mA). Additionally, the GPE-3323 comes with a large LCD display for easy parameter monitoring and an intelligent temperature-controlled fan to reduce operational noise, making it suitable for various electronic testing and research applications.
Specifications
- Output Voltage0~32V / 0~6A
- Output Current獨立輸出
- Accuracy≦0.2% + 3mA
- Voltage Limit Regulation Rate電源調節率≦3mV / 負載調節率≦5mV
- Load Regulation5V±5%
- Current Limit Regulation Rate6A
- 5V 固定輸出調節率電源調節率 ≦3mV / 負載調節率 ≦5mV
- Voltage Ripple≦1mVrms (5Hz~1MHz)
- Current Ripple≦3mArms
Features
- Channels單通道
- Output Control10mV / 1mA (設定與回讀)
- Independent Output SwitchOn/ Off開關
- Resolution後面板具簡易外部控制功能
- External Control具電壓/電流設定及回讀參數檢視功能
- Parameter Readback具面板鎖功能、智慧型溫控風扇，降低運轉噪音
- Overload Protection過載與過壓保護
- Other Functions具面板鎖功能、智慧型溫控風扇，有效降低運轉噪音
Attributes
- Operating Temperature0~40°C / lower than 70%RH without dew
- Storage Temperature-10~60 °C / lower than 80%RH without dew
- Altitude LimitLower than 1,000 meters
- Display4.3 " LCD Display
- ResolutionVoltage :100mV / Current :10mA
- AccuracyVoltage ±(0.1% of reading +30mV) / Current ±(0.3% of reading +6mA)
- Power SupplyAC100V/120V/220V±10%; 230V(+10%~-6%); 50/60Hz
- Dimensions210(W) x 155(H) x 306(D) mm
- WeightApprox. 7 kg
- AccessoriesPower Cable、Test Lead *3
