30V/6A DC Power Supply
Brand
GWINSTEK
|
Model
GPD-3303S
|
🇨🇳 China
• Three output channels with a maximum voltage of 30V and current of 3A
• Resolution of 1mV / 1mA, providing excellent settings and readback capability
• Automatic series/parallel function, user-friendly panel interface
• Four memory functions for quick access to settings
• Key lock and smart temperature control fan to reduce operational noise
• Equipped with USB standard interface and PC software for convenient connection and operation
Out of Stock
Views: 4
Description
The GPD-3303S 30V/6A DC Power Supply leverages the technological quality advantages of GW Instek in power supply research and development. It features three output channels, digital control, and a high-brightness LED display. With a precision of three decimal places and four memory settings, it is ideal for use in electronics, academic research laboratories, and personal research studios.
Specifications
- CH1 / CH2 電壓輸出0.0~30.000V
- CH1 / CH2 電流輸出0.00~3.0000A
- CH3 輸出2.5V / 3.3V / 5.0V
- 介面獨立輸出 / 串聯模式 / 並聯模式
- 定電壓調節率≦0.01%+3mV
- 電壓負載調節率≦0.01% + 3mV (額定電流≦3A) ; ≦0.01% + 5mV (額定電流≦10A) ; ≦0.02% + 5mV (額定電流≧10A)
- 輸出電壓電源調節率≦5mV / 負載調節率≦10mV
- CH1 / CH2 雜訊≦10mVpp 5~1MHz
- 限電流調節率≦0.2% + 3mA
- 電流負載調節率≦0.2% + 3mA
- CH3輸出2.5V/3.3V/5.0V 三段輸出選擇
- 精確度≦2mVrms
- 輸出電流3A
Features
- 通道數三通道
- 串並聯自動串並聯功能
- 解析度1mV / 1mA
- 輸出On/ Off開關
- 面板控制友善的操作介面，粗/細調控制
- 記憶功能4組保存/取回
- 其他功能具按鍵鎖定、智慧型溫控風扇，有效降低運轉噪音，具備USB標準接頭與PC軟體
Attributes
- Operating Temperature0~40°C / lower than 70%RH without dew
- Storage Temperature-10~60 °C / lower than 80%RH without dew
- Elevation LimitationLower than 1,000 meters
- Header Display0.4“ LED Display
- ResolutionVoltage :1mV / Current :1mA
- Program Control AccuracyVoltage : ±(0.03% of RDG+ 10 digits) / Current : ±(0.3% of RDG + 10 digits)
- Power SupplyAC 100V/120V/220V/230V±10%,50/60Hz
- Dimensions210(W) x 155(H) x 306(D) mm
- WeightApprox. 7 kg
- AccessoryPower Cable、Test Lead
