16-Channel Thermocouple Input Recorder
Brand
TECPEL
|
Model
DTM-T16
|
🇨🇳 China
The DTM-T16 offers a wide temperature measurement range and supports various thermocouple types, ensuring data accuracy and easy access with its high resolution and storage capacity, making it an ideal solution for high-demand applications.
Key features:
● 16-channel thermocouple input
● 5-inch capacitive touchscreen, resolution 800×480
● Real-time monitoring with graphical and digital display modes
● Data logging: Up to 100,000 data points per session, total storage up to 8 million points
● Supports USB or SD card (up to 32GB) for CSV data export
● Ethernet support: 10/100 Mbps, full-duplex/half-duplex
● Built-in memory: 32GB
● 1-second sampling and recording interval
● Rechargeable battery: 5000mAh
● Supports thermocouple types: K, J, E, T, R, S, N, B, C
Downloads
Price
NT$ 33,600
In Stock
Views: 7
Description
The DTM-T16 is a precision temperature measurement instrument designed with 16-channel thermocouple input, suitable for various industrial and laboratory needs. Its large-capacity recording capabilities and support for multiple temperature types make it an ideal choice for temperature monitoring. Whether for laboratory research or industrial applications, the DTM-T16 provides high accuracy data logging and real-time monitoring.
Specifications
- Screen Size5-inch capacitive touch screen
- Resolution800×480
- Number of Channels16-channel universal thermocouple input
- Display ModeReal-time monitoring, graphic and digital display
- Sensor TypeThermocouple (K, J, E, T, R, S, N, B, C)
- BandwidthEthernet transmission rate: 10 Mbps / 100 Mbps
Features
- Recording IntervalMinimum 1 second
- Recording ModeCSV format, supports loop/one-time recording
- Storage TemperatureSingle file capacity: 100,000 records, total capacity: 8 million records, built-in 32GB
- Number of Channels16-channel universal thermocouple input
- Built-in Memory32GB
- Maximum Storage Capacity8 million records
Attributes
- Operating TemperatureOperating temperature: -10 °C to 50 °C, Relative humidity: 5% to 95% RH (non-condensing)
- Storage TemperatureStorage temperature: -20 °C to 60 °C
- Transmission MethodUSB 2.0, SD card (up to 32GB), RJ-45
- Display5-inch capacitive touchscreen, Resolution: 800 × 480
- Battery Capacity5000 mAh
- Dimensions189.3 × 103.5 × 39 mm (with protective case)
- MaterialPC/ABS and TPE protective components
