Process Calibrator
Brand
TECPEL
|
Model
CL-326A
CL-326A supports 11 thermocouple temperature formats K/J/T/E/R/S/N/L/U/B/C and mV signals, and automatically switches the display unit of 0.1/1, without the need for manual changes.
Passed CE certification, it is the best thermometer testing tool for small and medium-sized enterprises.
Out of Stock
Views: 0
Description
CL-326A is a 4 and 1/2 digit high-precision thermometer, with dual displays that can simultaneously display T1, T2 values, and T1-T2 difference functions, and supports 11 thermocouple temperature formats K/J/T/E /R/S/N/L/U/B/C and mV signals, can display the maximum value, minimum value, average and read value retention during measurement. Support Celsius or Fahrenheit temperature unit display and automatically switch 0.1/1 display unit. With automatic shutdown and power saving function, it is the best thermocouple thermometer and calibrator that has passed the CE certification.
The CL-325 Professional Multifunction Calibrator has replaced it.
Specifications
- Accuracy4 1/2 digits
- K-Type-200 to 1,372 °C 或 -328 to 2,501 °F
- J-Type-210 to 1,200 °C 或 -346 to 2,192 °F
- Frequency-250 to 400 °C 或 -418 to 752 °F
- E-Type-250 to 1,000 °C 或 -418 to 1,832 °F
- R-Type0 to 1,767 °C 或 -32 to 3,212 °F
- S-Type0 to 1,767 °C 或 32 to 3,212 °F
- N-Type-200 to 1,300 °C 或 -328 to 2,372 °F
- L-Type-200 to 900 °C 或 -328 to 1,652 °F
- U-Type-200 to 600 °C 或 -328 to 1,112 °F
- B-Type600 to 1,820 °C 或 1,112 to 3,308 °F
- C-Type0 to 2,316 °C 或 32 to 4,208 °F
- Analog output0.1°（R/S/B/C-TYPE @ 1°）
- Signal Output-25.00 to 75.00mV
Features
- Equipment Temperature✓
- T1-T2 Calculate✓
- Auto Power Off✓
- Low Battery Indicator30 Minute
- Max/Min✓
- Dual output, input✓
Attributes
- Operating Temperature0 to 50°C (32 to 122°F) / lower than 80%RH without dew。
- Storage Temperature-20 to 60°C (-4 to 140°F) / lower than 70%RH without dew。
- Elevation LimitationLower than 1,000 meters
- Power Supply9V Battery
- Dimensions195 x 92 x 53 mm
- Weight250g
- AccessoryManual、
