Carbon Dioxide and Temperature Display
Brand
TECPEL
|
Model
ZG-106
|
🇨🇳 China
The ZG-106 provides carbon dioxide and temperature measurement functions. It is designed for easy portability and is suitable for various applications.
- Features a 48-hour data logging function for tracking changes in CO2 concentration
- Alarm function can automatically remind users when CO2 concentration is too high
- Built-in low-battery indicator to ensure safe operation
- Supports multiple mode settings to meet different needs
Price
NT$ 3,990
Out of Stock
Views: 69
Description
Product: ZG-106, Field: Function Introduction
The ZG-106 CO2 and temperature display is a flexible and lightweight monitoring instrument designed for indoor environments. It not only precisely measures CO2 concentration, but also simultaneously monitors ambient temperature and humidity to ensure users’ health and safety. The device is ideal for use in public places such as offices, schools, exhibition halls, shopping malls, conference rooms, gyms, and restaurants. It helps control air quality and issues timely alarms to alert users to air quality conditions.
Specifications
- CO2 Range±50ppm @ less than 1,000ppm, the rest is 5%
- Temperature Range0~50 °C
- Resolution0.1 °C (0.1 °F)
- Repeatability±20 ppm
- Temperature CoefficientValue change by ±0.1% or ±2 ppm per 1°C, whichever is greater
- Pressure Coefficient0.13% of the reading per mmHg (you can input the correct height yourself)
- Warmup TimeAbout 15 seconds after power-on to display the concentration value
- Response TimeAbout 2 minutes (63% of the change)
- Warm-up TimeLess than 60 seconds at 22 °C
- Temperature Unit Selectable °F / °C, or Off.
- 讀值的0.13% /毫米汞柱 (可自行輸入正確的高度)0,13 % de la valeur lue / mmHg (vous pouvez saisir la hauteur correcte)
- 開機後約15秒顯示濃度值Environ 15 s après la mise sous tension, affichage de la valeur de concentration
- 大约2 分鐘 (63%的變換)Environ 2 minutes (conversion de 63 %)
- 小於60 秒 在 22 °C< 60 s à 22 °C
- °F / °C, or Off. °F / °C, ou Off.
Features
- Data LoggingCan record CO2 and temperature measurement values from the past 24 hours, with one record every 30 minutes (48 records in total)
- Low Battery IndicatorCan record the maximum and minimum CO2 measurement values since the device was powered on
- Alarm FunctionCan trigger an alarm when the CO2 concentration reaches 1000 ppm, and the alarm value (in ppm) can also be adjusted manually
- Restore factory modeCan restore factory settings to facilitate adjustment or repair
- Multiple mode adjustment parameter settingsIncludes altitude mode, alarm mode, outdoor mode, user calibration mode, and data log mode
Attributes
- Operating Temperature0~50 °C / Less than 95 %RH No condensation
- Storage Temperature-10~40 °C / Less than 70 %RH No condensation
- Altitude LimitBelow 1,000 meters
- Sensor TypeNDIR (Non-dispersive infrared method)
- Power SupplyDC 1.5V AA battery x 4 or DC6V power adapter
- Battery LifeApproximately 80 hours
- Dimensions166 × 81 × 26 mm
- Weight273.6 g (including battery)
- AccessoriesUser manual, batteries
