60MHz Function Signal Generator arbitration function generator

Brand UNI-T | Model UTG-2062B | 🇨🇳 China
60MHz Function Signal Generator arbitration function generator
● Sampling Rate: 1.28GSa/s ● Vertical Resolution: 16bits ● Waveform Types: 7 standard waveforms ● Frequency Range: 100mHz ~ 200MHz ● Built-in 16th Harmonic Generator ● Digital Interface: USB Host, USB Device, LAN ● Duty Cycle Adjustment Range: 0.001% ~ 99.999% ● Output Voltage: TTL Compatible ● Interface Support: English/Chinese
Out of Stock
Views: 61

Description

The UTG-2062B is a high-performance 60MHz function signal generator, featuring a fast sampling rate of 1.28GSa/s and a high vertical resolution of 16bits, capable of generating up to 7 standard waveforms. With its built-in 16th harmonic generator and unique expression output function, it is suitable for various testing and experimental needs. Whether for academic research or engineering applications, the UTG-2062B provides accurate and reliable signal output.

Specifications

  • Display4.3" TFT LCD, WVGA(480×277)
  • Sound Frequency60MHz
  • Channels2通道
  • Frequency320MS/s
  • Accuracy±0.5ppm @ 25°C
  • Sampling Rate1.2GS/s, 300MS/s(DDS模式)
  • Signal OutputSine, Square, Ramp, Harmonic, Pulse, Noise, DC, Arb, AM, FM, ASK, FSK, OSK, PSK, PWM
  • Resolution16位元
  • Sine Wave1μ~60M Hz
  • Square Wave1μ~60M Hz
  • Triangle Wave1μ~3M Hz
  • Harmonics1μ~30M Hz
  • Waveform1μ~15M Hz
  • Sound Level60M Hz (-3dB)
  • Internal I/O Frequency Range10MHz±50Hz
  • Output VoltageTTL兼容
  • External I/O Frequency Range10MHz±50Hz
  • External I/O Impedance50Ω

Features

  • Waveform7種標準波型
  • Overshoot< 2%
  • Duty Cycle0.001% ~ 99.999%
  • Symmetry週期 1% + 4ns
  • CommunicationUSB Host、USB Device、LAN
  • Interface英/中
  • Frequency100mHz ~ 200MHz
  • Input Coupling交流/直流

Attributes

  • Operating Temperature0 to 40 °C / lower than 90%RH without dew。
  • Storage Temperature-20 to 60 °C / lower than 60%RH without dew。
  • Altitude LimitLower than 2,000 meters
  • Power SupplyAC100 to 240V，50/60Hz , 100 ~ 120Vrms (± 10%), 400 Hz
  • Dimensions320 × 230 × 93 mm
  • WeightApprox. 3.1 kg
  • AccessoriesTransmission line, CD, instruction manual, power cord, signal pair wiring (BNC-BNC), alligator clip cable
