Digital Multimeter
Brand
PROVA
|
Model
PROVA-803
|
🇹🇼 Taiwan
PROVA-803 Digital Multimeter 60,000 resolution (4 5/6 bit) and dual channel input
Price
NT$ 5,355
Out of Stock
Views: 0
Description
PROVA-803 A handheld multimeter with complete functions, stable performance, and high precision. It is an ideal tool for circuit/electric equipment maintenance and repair.
60,000 resolution (4 5/6 bit) and dual channel input
■ 0.1% DC voltage and 0.2% AC voltage accuracy (best)
■ 10KHz (maximum) bandwidth
■ Accurate and rapid response to AC voltage and current
■ Better AC accuracy than desktop meters
■ More functions than desktop meters
■ 1/7 the price of a desktop meter
■ Like a dual-channel oscilloscope, it can observe and record the voltage relationship between two points
■ Can observe and record the relationship between current and voltage
■ Simultaneous display of frequency and duty cycle
■ Use a personal computer to record dual-channel data through the RS-232 interface
■ Dual channel recording 10,708 independent data
Specifications
- DC VoltageBest Value ±(0.5%+1)
- DC CurrentBest Value ±(1%+3)
- AC VoltageBest Value ±(1%+3)
- AC CurrentBest Value ±(1.5%+5)
- ResistanceBest Value ±(1%+2)
- CapacitanceBest Value ±(3%+5)
- Temperature Range-40 ~ 1,000°C
- FrequencyBest Value ±(1.2%+3)
- Temperature DeviationBest Value ±(1.2%+3)
Features
- Frequency45~1kHz
- Duty Ratio0.1% ~ 99.9%:
Attributes
- Operating Temperature0~40°C / lower than 70%RH without dew
- Storage Temperature-10~50°C / lower than 80%RH without dew
- Elevation LimitationLower than 1,000 meters
- Power SupplyDC 9V battery X1
- Dimensions180 X 87 X 47 mm
- WeightApprox. 370g (Battery Including)
- AccessoryTest Lead、Battery、Conversion Seat、Type-K Thermocouple Probe、USB Cable、Software、Manual
