CH1/CH2: 0 ~ 30V / 0 ~ 6A Output DC Power Supply

GPP-3060/6030/3650 three-channel programmable DC power supply is an extension of the GPP-X323 series. The maximum output power of these two models is 385W. GPP-3060 supports CH1/CH2: 0 ~ 30V / 0 ~ 6A output GPP-6030 supports CH1/CH2: 0 ~ 60V / 0 ~ 3A output GPP-3650 supports CH1/CH2: 0 ~ 36V / 0 ~5A output All three models of CH3 support 1.8V, 2.5V, 3.3V, 5.0V/5A. GPP-3060/6030/3650 inherits the high setting resolution (1mV/0.1mA) and display resolution (0.1mV/0.1mA) of the GPP series, and its low ripple noise characteristics are ≦1mVrms/≦2mArms and ≦100µs Output transient recovery capability, and provide independent output switches for each channel. The unique load function of the GPP series can be set to the power supply or load (Load) function in CH1/CH2. For example, one channel is the power output, and the other channel is set as the load function to consume the power of the object under test, which can meet the needs of a single power supply for simple basic battery charge and discharge or load characteristic testing; The sequence output function (Sequence) allows users to edit the power output waveform themselves, and also allows users to set a sequence of constant voltage (CV) or constant current (CC) load waveforms. For example, sequential power output or dynamic load simulation testing; Channel 3 (CH3) adds a 3A USB (Type A) output terminal, which can be used for USB charging tests. Suitable for application areas Scientific research and experimental testing Battery charge and discharge test Electronic parts measurement 3C electronic product measurement
