AFG-2105 Arbitrary Function Generator
Brand
GWINSTEK
|
Model
AFG-2005
|
🇨🇳 China
The AFG-2005 series arbitrary waveform/function generators are built with DDS technology to deliver highly stable, high-precision signal output, providing a 5 MHz bandwidth to meet a wide range of testing needs.
In addition to basic waveforms, they also support noise and arbitrary waveform output, along with modulation, sweep, and counter functions, greatly enhancing application flexibility. The intuitive digital operation interface and large LCD display make parameter setup faster and clearer.
Out of Stock
Views: 2
Description
GWInstek AFG-2005 Arbitrary Function Generator (5 MHz): The photos are from the series and for reference only. They are not the actual products.
Frequency Range: 0.1 Hz to 5 MHz with 0.1 Hz resolutionWaveforms: Sine, Square, Triangular, Noise, and ArbitrarySampling Rate: 20 MSa/s with 10-bit vertical resolution and 4k point memory for arbitrary waveformSquare Wave Duty Cycle: Adjustable from 1% to 99%Parameter Setting: Numeric keypad entry and knob selection for waveform parameter adjustmentDisplay: 3.5” LCD screen displaying amplitude, DC offset, and other key settings simultaneouslyUSB Device Interface: For remote control and waveform editingPC Software: Includes software for arbitrary waveform editing
Specifications
- Display3.5” LCD, displaying amplitude, DC offset, and key settings
- Frequency Range0.1 Hz to 5 MHz 0.1 Hz resolution
- Number of Channels1 channel
- Sampling Rate20 MSa/s
- Accuracy±20 ppm
- Arbitrary Waveform Reconstruction Rate10MHz
- Sine Wave0.1Hz ~3 M Hz
- Square Wave0.1Hz ~3 M Hz
- Triangle Wave0.1Hz ~3M Hz
- Arbitrary Waveform0.1Hz ~ 3M Hz
- Amplitude3M Hz (-3dB)
- Internal Input/Output Frequency Range3 MHz±50Hz
- Output Signal4k points arbitrary waveform
- Output VoltageTTL compatible
- External Input/Output Frequency Range3MHz±50Hz
- External Input/Output Impedance50Ω
- Resolution10-bit
- Square Wave Duty Cycle1% to 99% adjustable
Features
- WaveformSine wave, square wave, triangle wave, noise, arbitrary waveform
- Output SignalSine wave, square wave, triangle wave, noise wave, arbitrary wave
- Waveform Characteristics5 standard waveforms: sine wave, square wave, triangle wave, noise wave, arbitrary wave
- Overshoot< 2%
- Duty Cycle0.001% ~ 99.999%
- SymmetryPeriod 1% + 4ns
- Digital TransmissionUSB Host, USB Device
- InterfaceEnglish/Chinese
- Frequency5Hz to 150MHz
- Coupling MethodAC/DC
- Numeric Keypad InputSupported
- Knob SelectionSupported
- Remote ControlSupported
- Parameter SettingNumeric keypad input and knob selection
- PC SoftwareProvides arbitrary waveform editing
Attributes
- Operating Temperature0~40 °C / Below 90%RH, non-condensing
- Storage Temperature-20~60 °C / Below 60%RH, non-condensing
- InterfaceUSB
- USB Device InterfaceSupports remote control and waveform editing
- Altitude LimitationBelow 2,000 meters
- Power SupplyAC 100 - 240V, 50/60Hz
- Dimensions266(W) x 107(H) x 293(D) mm
- WeightApprox. 2.5 kg
- AccessoriesCD, quick start guide, power cord, GTL-101 alligator clip cable x2
