Non contact Phase Sequence Meter
Brand
TECPEL
|
Model
PHS-865
|
🇹🇼 Taiwan
Key features of the PHS-865 Non-contact Phase Sequence Meter include:
- Detection of phase loss and phase sequence
- Automatic shutdown function (approximately five minutes)
- Safe and easy crocodile clip design
- Strong magnets on the back for convenient fixing
Price
NT$ 2,835
Out of Stock
Views: 0
Description
The PHS-865 Non-contact Phase Sequence Meter is designed for detecting three-phase electrical equipment, offering dual functionality for phase loss and phase sequence detection. With a safe non-contact measurement method, users can quickly test by simply clamping the crocodile clip onto the outer power line. It also features an automatic shutdown function to extend battery life, and four strong magnets on the back for easy fixation during operation, enhancing efficiency and safety.
Specifications
- 量測範圍AC 110~600 V
- 頻率45~70 Hz
- 電源約7mA / 單相
Features
- 安全等級CE marks EN 6101-1 CAT. III. EN 61010-2-031
Attributes
- Operating Temperature0~50°C / lower than 80%RH without dew。
- Storage Temperature0~50°C / lower than 70%RH without dew。
- Elevation LimitationLower than 2,000 meters
- Dimensions102 × 78 × 32.5 mm
- Weight228g
- AccessoryCarry holster, Instructions
