VD-16 Non Contact Voltage detector

Name: TECPEL VD-16 Non Contact Voltage detector
Brand: TECPEL
SKU: VD-16

Brand TECPEL | Model VD-16 | 🇨🇳 China

Non-contact AC voltage detector (electroscope) VD-16 This model can know whether there is electricity by touching the wire sheath?!? It can also test whether the live wire and the ground wire are connected incorrectly. It can be used for audio power or precision instrument power detection. Applicable: Check whether there is any household or industrial power. Leakage of electricity, check whether the socket has electricity, check and repair the control panel...etc.

Out of Stock

VD-16 Voltage detector * Convenient AC voltage tester that indicates the presence of AC 5 ~ 1,000V * The Voltage tester pen can help you find broken, and live wires * Low to High sensitivity adjustment. * Sensitivity adjustable for non contact detection * Able to test light sockets and locates the short circuit. * White LED light * Power on off switch * Detecting red lamp alert * The voltage tester pen is ideal for home.

Operating Temperature0 ~ 40°C
Humidity RangeLess than 85%RH
Sensing Voltage1,000 Volts (V)
Frequency50 - 400 Hertz (Hz)
Power Supply1.5V button cell, AAA or equivalent battery, 2 pieces
Voltage Detecting Range5V ac - 1000V ac
Sound Frequency50Hz/400Hz
Safety RatingCAT IV 1000V
Dimensions154×32
Weightabout 50 g (including battery)
Detection Range5V AC - 1000V AC
Sensor TypeNon-contact
Measurement TypeAC Voltage
Measuring Range50V to 1000V AC
Accuracy±1.5%

Flashlight Functionyes
AC Voltageyes
Light Intensityyes
Non-contact Detectionyes
Adjustable Sensitivityyes
Safety RatingCAT IV 1000V
Alarm FunctionAudio and Visual Alert
Battery LifeApprox. 150 hours
Auto Power OffYes

Dimensions154×32
WeightApprox. 100g
AccessoryUser Manual, Battery AA×2
Power Supply1.5V button cell, AAA or equivalent battery, 2 pieces
Operating TemperatureTemperature 0 ~ 50°C, Humidity below 70%RH without condensation
Length150 mm
