50MHz Desktop Digital Oscilloscope
Brand
GWINSTEK
|
Model
GDS-1052-U
■ 50 MHz bandwidth, 2 input channels
■ 250MSa/s real-time sampling rate and 25GSa/s equivalent sampling rate
■ 4k memory depth/CH
■ Peak detection up to 10ns
■ 15 panel settings and waveform storage/retrieval
■ 5.7" TFT full-color display
■ 19 automatic measurements
■ Horizontal scan: 1nS ~ 50S/div
■ Supports USB Host and Device access
■ Go/NoGo test function
■ Data logger
Out of Stock
Views: 58
Description
The GDS-1000-U series desktop digital oscilloscope offers a bandwidth of 50MHz and a dual-channel design, making it suitable for various educational and industrial applications. With an intuitive interface and a 5.7-inch color TFT LCD display, users can enjoy an unparalleled measurement experience. The oscilloscope features a fast 250MSa/s real-time sampling rate and a 25GSa/s equivalent sampling rate, ensuring accurate signal analysis with high-resolution waveform capture.
Specifications
- Bandwidth50MHz
- Channels8 Bit
- Sampling Rate25G Sa/s
- Memory Depth小於 7ns
- Resolution4K
- Rise Time2
- Input Impedance300V (DC+AC peak), CAT II
- Overload Protection± 3% full scale
- Trigger Accuracy1MΩ ±2%, ~15pF
Features
- Wave Trigger正體中文／簡體中文／英文等
- Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/Overshoot, Fall Preshoot/Overshoot
- Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, – Width, Duty Cycle
- Multi-language Interface15筆
- Signal OutputUSB 2.0 full speed (CDC-ACM)
Attributes
- Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
- Storage Temperature-20~70°C / Below 70%RH @70°C, no condensation
- Altitude LimitLower than 1,000 meters
- Power SupplyApprox. 18W, 40VA maximum
- Fuse1A slow, 250V
- Display5.7 inch, TFT, Brightness Adjustable
- Interface310(W) x 142(H) x 140(D) mm
- DimensionsApprox. 2500g
- WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
- Accessories示波器測棒x2、示波器測棒調整工具、傳輸線、光碟、說明書
