Insulation Resistance Tester

Brand UNI-T | Model UT512 | 🇨🇳 China
Insulation Resistance Tester
UT512 - 1
UT512 - 2
The UT512 offers multiple test voltage options, catering to a variety of applications and measurement needs. It is equipped with data storage and auto shutdown features, and can measure Polarization Index (PI) and Dielectric Absorption Ratio (DAR).
Out of Stock
Views: 2

Description

The UT-512 Insulation resistance tester 0.5MΩ ~ 100 G Ω, 500, 1000, 1500, 2500V is a testing instrument designed for measuring the insulation resistance of large transformers, generators, and high-voltage equipment. It offers multiple testing voltage options and a wide measurement range, making it ideal for professional electricians. UT-511 High Insulation Resistance Meter 0.1MΩ ~ 10 G Ω, 100, 250, 500, 1000V UT-512 High Insulation Resistance Meter 0.5MΩ ~ 100 G Ω, 500, 1000, 1500, 2500V UT-513A high insulation resistance meter 0.5MΩ ~ 1000 G Ω, 500, 1000, 2500, 5000V

Specifications

  • Test Voltage Options100V, 250V, 500V, 1000V
  • Insulation Resistance0.1MΩ to 10GΩ ±(3%+5)
  • DC Voltageup to 1000V ±(2%+3)
  • AC Voltageup to 750V (50/60Hz) ±(2%+3)
  • Low Resistance Measurement0.1Ω to 999.9Ω ±(1%+3)
  • Short Circuit Currentless than 2mA
  • Test Voltage500V, 1000V, 2500V, 5000V
  • Resistance0.5MΩ ~ 1000GΩ
  • Accuracy±3%

Features

  • Auto RangeYes
  • Data Logging18 sets of measurements
  • Auto Power OffYes
  • PI and DAR MeasurementYes
  • Test Time Settingup to 30 minutes
  • Comparison FunctionYes
  • Backlightyes
  • Overrange and High/Low Voltage WarningYes
  • Low Battery IndicatorYes
  • Max Display9999 digits
  • Automatic Dischargeyes
  • Data Holdyes

Attributes

  • Power SupplyAA batteries × 6
  • Dimensions200mm x 100mm x 50mm
  • Body ColorIron Gray
  • Weight1.5kg
  • Body Dimensions202 x 155 x 94 mm
  • AccessoryPower Adapter (extra purchase required)
  • Operating Temperature0 ~ 40°C
