True RMS Digital Multimeter

Brand UNI-T | Model UT17B_Max | 🇨🇳 China
UT17B MAX True RMS multimeters have a compact and portable design, fast response, and strong anti-interference to EMC interference. They come with standard gold-plated test leads and gold-plated fine-tipped test leads. They also feature full-range 1000V input protection, making them the ideal tool for electronic and electrical engineers.
Out of Stock
Views: 0

Description

The UT17B MAX True RMS digital multimeter features gold-plated standard test leads and full-range 1000V input protection, making it ideal for electronic and electrical engineers. The UT17B Max True RMS Digital Multimeters have a compact and portable design, fast response, strong anti-interference to EMC interference, and come with standard gold-plated test leads and gold-plated fine-tipped test leads. It also features full-range 1000V input protection, making it the ideal tool for electronic and electrical engineers. A variable frequency drive (VFD) is a motor control device that drives a motor by regulating the frequency and voltage of a power supply. The VFD can also control the motor's acceleration during start or deceleration during stop.

Specifications

  • DC Voltage600.0mV/6.000V/60.00V/600.0V/1000V ±(0.4%+3)
  • AC Voltage600.0mV/6.000V/60.00V/600.0V/1000V ±(0.5%+5)
  • VFD (Voltage)600.0V ±(8%)
  • AC Current600.0µA/6000µA /60.00mA/600.0mA/6.000A/10.00A ±(1.2%+3)
  • DC Current600.0µA/6000µA /60.00mA/600.0mA/6.000A/10.00A ±(1.2%+3)
  • Resistance600.0Ω/6.000kΩ/60.00kΩ/600.0kΩ/6.000MΩ/60.00MΩ ±(0.5%+2)
  • Capacitance6.000nF/60.00nF~600.0µF/6000µF ±(2.0%+5)
  • Frequency10Hz~10MHz ±(0.1%+3)
  • Duty Cycle1%~99.9% ±(1.0%+4)
  • Temperature (℃/℉)-55℃500℃/–67°F932°F ±2℃/±4℉

Features

  • Display Count6000
  • ContinuityYes
  • Data HoldYes
  • Max/MinYes
  • Relative ModeYes
  • BacklightYes
  • Auto RangeYes
  • Auto Power OffYes
  • Safety RatingYes
  • Alarm FunctionYes
  • Any-key Wake UpYes
  • Overvoltage CategoryCATⅢ 600V

Attributes

  • Power Supply2*1.5V AA
  • Product Color426U+1797C
  • Weight455g
  • Dimensions182mm91mm45mm
  • Accessory1 pcs User manual, two pair Test lead (normal gold plated probe & Fine-tipped probe), 1 pcs K-type thermocouple (UT17B/UT18B MAX only), 2 pcs battery, Magnetic hanger (optional)
  • SPQ10 pcs
  • Package Dimensions480×370×195mm
