Battery Tester

Brand TES | Model TES-33S | 🇹🇼 Taiwan
Battery Tester
TES-33S - 1
TES-33S - 2
TES-33S - 3
TES-33S - 4
TES-33S - 5
The TES-33S offers quick testing functionality for rechargeable batteries, featuring: - Measurement of internal resistance, voltage, current, and temperature - USB connectivity to a computer for data analysis - Automatic measurement value lock and data storage functionality - Comparator setting function displaying PASS, WARNING, FAIL status - Manual and automatic data storage (999 entries) - Continuous automatic data logging to micro SD card (4GB, 99 blocks)
Price NT$ 18,500
Out of Stock
Views: 0

Description

The TES-33S Battery Tester is an efficient device designed for testing the capacity and health status of rechargeable batteries. It supports various battery types, including alkaline and lead-acid batteries, and offers multi-measurement features such as internal resistance, voltage, and temperature. This instrument is suitable for industrial applications, allowing precise testing without interrupting battery operation, ensuring reliability and safety.

Specifications

  • 可測電池型式充電式電池、鹼性電池、鉛酸電池
  • 電池容量0 to 1200安培小時
  • 電阻<檔位:> 4mΩ,40mΩ,400mΩ,4Ω,40Ω,400Ω; <解析度:> 1mΩ,10mΩ,100mΩ,1mΩ,10mΩ,100mΩ; <準確性:> ±(3%讀值±20位)在4mΩ檔位, ±(0.8%讀值±6位)在其它檔位
  • 電壓值<檔位:> 6V, 60V; <解���度:> 1mV, 10mV; <準確性:> ±(0.1%rdg±6位)
  • 工作溫度範圍: -20℃至60℃ (-4℉至140℉) ±1℃ / ±1.8℉

Features

  • 快速測試yes
  • 自動測量值鎖定yes
  • 自動資料存入yes
  • 比較器設定功能yes
  • 安全等級PASS，WARNING，FAIL
  • 資料記錄micro SD卡4GB (99個區塊)

Attributes

  • DimensionsApprox. 198(L)x94(W)x49(H) mm / Approx. 530g (including batteries)
  • Overload Protection60VDC
  • Power Supply6 alkaline batteries or power adapter
  • AccessoryLarge clip test line, small clip test line, probe test line, 3092CP DC current converter, zero adjustment board, manual, batteries, power adapter, USB cable, software CD, carrying case
