Handheld Infrared Thermometer Gun
Brand
TECPEL
|
Model
NP-15-LT
|
🇨🇳 China
The NP-15-LT infrared thermometer is a professional-grade infrared thermometer specifically designed for industrial measurement and high-temperature inspection needs, combining high accuracy, fast response, and long-distance measurement capability. It is suitable for applications such as equipment inspection, process monitoring, machinery maintenance, and quality management.
It features a wide measurement range of -30°C to 900°C, meeting diverse needs from low-temperature environmental monitoring to high-temperature equipment inspection. With optical resolution up to 75:1, it can still accurately target small-area objects for measurement even at long distances, with a minimum spot size as small as 1 mm. This makes it especially suitable for inspecting electronic components, precision machinery, and high-density equipment.
Price
NT$ 12,000
In Stock
Views: 48
Description
The NP-15-LT features a dual laser targeting design that clearly indicates the actual measurement area, reducing measurement errors and improving on-site operational efficiency. With a response time as fast as 300 ms, it can capture rapidly changing temperature conditions in real time, helping users quickly identify abnormal heat sources and equipment changes.
In addition, it has built-in high/low temperature alarm functions that provide both visual and audible alerts, effectively enhancing on-site safety monitoring and abnormal condition warning capabilities. Equipped with a 4-digit backlit LCD display, it ensures clear reading of measurement data even in dim or complex environments.
In addition to infrared measurement, it also supports Type K thermocouple input for contact temperature measurement based on different application needs, increasing overall flexibility of use. When used with STonline software, it enables data logging, analysis, and management, helping enterprises establish a more complete temperature monitoring and equipment maintenance process.
Specifications
- Sensor Type紅外線感應器
- Optical ResolutionSF 60:1 / CF 75:1
- 最小量測點1mm
- Response TimeLT/LR 300ms
- 輸入信號Type K 熱電偶
Features
- Alarm Function高/低溫警報(視覺及聲響)
- Display四位數背光 LCD
- 溫度儲存2,000 points
- Safety RatingUSB 接口
Attributes
- Dimensions163.5(L) x 207(H) x 70(W) mm
- Weight470g
- Power Supply9V Alkaline Battery
- Battery Life10 hours (laser and backlight on)
- Laser ClassIEC Class2 / FDA Class ǁ(<1mW)
