Function Signal Generator

Brand GWINSTEK | Model MFG-2110 | 🇹🇼 Taiwan
Function Signal Generator
Designed for users requiring high stability and diverse output functions, the MFG-2110 features: - Support for AM, FM, PM, PWM, FSK modulation modes - Sweep mode selectable between linear or logarithmic - Sweep time range from 1ms to 500s - Fixed output impedance of 50Ω - 4.3 inch TFT LCD display (480 × 272)
Out of Stock
Views: 0

Description

The MFG-2110 Function Signal Generator provides precise frequency and waveform outputs, making it suitable for various applications in research, engineering, and testing. Featuring a high-resolution display and diverse modulation capabilities, it enhances user experience. Whether for signal simulation or testing environments, the MFG-2110 meets the demands for high stability and precision.

Specifications

  • 頻率範圍10MHz
  • 頻率1μHz
  • 正弦波 (Sine)10MHz (最大)
  • 方波 (Square)10MHz (最大)
  • 三角波、斜波 (Triangle, Ramp)1MHz
  • 振幅範圍50Ω 負載: 1mVpp 至 10Vpp
  • 直流偏移範圍 (Offset)±5 Vpk AC+DC (50Ω 負載)

Features

  • 調變模式支援 AM, FM, PM, PWM, FSK
  • 掃描模式 (Sweep)線性或對數
  • 掃描時間範圍1ms 至 500s
  • 輸出阻抗50Ω (固定)
  • 顯示器4.3 吋 TFT LCD (480 × 272)

Attributes

  • Dimensions266mm (W) × 107mm (H) × 293mm (D)
  • WeightApprox. 2.5kg
  • Operating Temperature0°C to 40°C
  • Storage Temperature-10°C to 70°C
  • Power SupplyAC100-240V, 50-60Hz
