200MHz 2-channel Desktop Digital Oscilloscope

Brand GWINSTEK | Model MDO-2202A
200MHz 2-channel Desktop Digital Oscilloscope
■ Analog Channels: 2 channels ■ Real-time Sampling Rate: Up to 2GSa/s ■ Memory Depth: 20M per channel ■ Waveform Update Rate: 120,000 wfms/s ■ VPO Display Technology ■ 8" WVGA TFT LCD Display ■ FFT Maximum: 1M points ■ High-pass/Low-pass/Band-pass Filters ■ 29,000 Segment Memory and Waveform Search Function ■ I2C/UART/CAN/LIN Triggering and Decoding ■ Supports Remote Network Storage
Out of Stock
Views: 55

Description

The MDO-2202A is a 200MHz 2-channel desktop digital oscilloscope featuring a maximum real-time sampling rate of 2GSa/s per channel, making it ideal for precision testing and analysis. With a memory depth of 29,000 segments and an advanced waveform search function, it enhances testing efficiency. The oscilloscope is equipped with an 8-inch WVGA TFT LCD display for clear waveform visualization, supports multiple triggering modes, and offers automatic measurement capabilities, making it suitable for development and maintenance in electronic products.

Specifications

  • Bandwidth200 MHz
  • Channels2 CH + EXT
  • Sampling Rate8 Bit
  • Memory Depth120,000 波形/每秒
  • Resolution小於 1.75 ns
  • Waveform Update Rate8 x 10 格
  • Rise Time最大 20 Mpts
  • Graticule300 Vrms, CAT I
  • Input Impedance± 3% full scale
  • Overload Protection約 1 MΩ // 16 pF
  • Trigger Accuracy24 組
  • Vertical Sensitivity-
  • Timebase Accuracy-

Features

  • Wave Trigger正體中文／簡體中文／英文...等
  • Waveform StorageCH1 ,CH2 Line, EXT
  • Auto Measurement6位數解析度，誤差±2％
  • Trigger Mode支援 100 ms/div 滾動模式或慢速
  • Trigger Type邊緣,脈衝寬度(突波),影像,脈衝,上升/下降（斜率）,交替,逾時,事件延遲(1〜65535 事件),延遲(持續時間,4nS〜10S),匯流排
  • Trigger CouplingAC, DC, LF rej., HF rej., Noise rej
  • Multi-language InterfaceUSB 2.0 , Ethernet(RJ-45), Go-NoGo BNC, Kensington Style Lock

Attributes

  • Operating Temperature0~40°C / Below 80%RH @40°C, no condensation
  • Storage Temperature-20~60°C / Below 70%RH @70°C, no condensation
  • Altitude LimitLower than 1,000 meters
  • DisplayApprox. 18W, 40VA maximum
  • Power Supply1A slow, 250V
  • Fuse8“ TFT WVGA color display
  • Interface384 X 208 X 127.3 mm
  • DimensionsApprox. 3kg
  • WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
  • Accessories示波器測棒x2、示波器測棒調整工具、傳輸線、光碟、說明書
