200MHz 4-channel Desktop Digital Oscilloscope

Brand GWINSTEK | Model GDS-2204A
200MHz 4-channel Desktop Digital Oscilloscope
■ 200MHz bandwidth, 4-channel design ■ 2GSa/s real-time sample rate, 100GSa/s equivalent sample rate ■ 2M memory depth ■ Standard built-in waveform search and segmented memory functions ■ Up to 80,000 waveforms per second update rate ■ Provides UART, I2C, and SPI triggering and decoding functions ■ Optional digital channels to upgrade to a mixed-signal oscilloscope ■ Flexible interface options, standard USB, optional LAN/GPIB ■ Free upgrades available for various advanced functions
Out of Stock
Views: 55

Description

The GDS-2204A digital oscilloscope is a high-performance desktop instrument featuring a bandwidth of 200MHz and a 4-channel design, specifically engineered for accurate measurement of complex signals. It boasts a long memory depth of 2M, allowing for extensive waveform data storage, along with standard waveform search and segmented memory functions. With vertical sensitivity down to 1mV/div and a time range from 1ns/div to 100s/div, it effectively captures weak signals and rapidly changing waveforms, making it suitable for various electronic testing needs.

Specifications

  • Bandwidth200MHz
  • Channels4
  • Sampling Rate8 Bit
  • Memory Depth80,000 波形/每秒
  • Resolution小於 1.75ns
  • Waveform Update Rate最大 10Mpts
  • Rise Time300Vrms, CAT I
  • Timebase Accuracy± 3% full scale
  • Input Impedance約 1MΩ// 16pF.
  • Overload Protection24 組
  • Trigger Accuracy±3% full scale
  • Vertical Sensitivity-

Features

  • Wave TriggerTraditional Chinese / Simplified Chinese / English
  • Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/ Overshoot
  • Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, – Width, Duty Cycle
  • Multi-language InterfaceCH1, CH2, CH3*, CH4*, Line, EXT
  • Signal OutputRS232, USB 2.0 , 網路(RJ-45), Go-NoGo BNC, Kensington Style Lock [選配 SVGA 影像埠]

Attributes

  • Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
  • Storage Temperature-20~60°C / Below 70%RH @35°C, no condensation
  • Altitude LimitLower than 1,000 meters
  • DisplayApprox. 18W, 40VA maximum
  • Power Supply1A slow, 250V
  • Fuse7“ TFT WVGA color display
  • Interface384 X 208 X127.3 mm
  • DimensionsApprox. 2800g
  • WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
  • Accessories示波器測棒x2、示波器測棒調整工具、傳輸線、光碟、說明書
