100MHz 2-channel Desktop Digital Oscilloscope
Brand
GWINSTEK
|
Model
GDS-2102E
|
🇹🇼 Taiwan
100MHz bandwidth, 2 channels
■ Real-time sampling rate of 1GSa/s per channel
■ Up to 1M point FFT for higher frequency domain resolution
■ Standard maximum memory depth of 10M and VPO waveform display technology
■ Waveform update rate up to 120,000 times per second
■ 8” WVGA TFT LCD display
■ High-pass and low-pass digital filter functionality
■ 29,000 segment memory and waveform search capability
■ I2C/SPI/UART/CAN/LIN serial bus triggering and decoding functions
■ Data logging ability to track signal changes for up to 100 hours
■ Supports remote network storage
Out of Stock
Views: 57
Description
The GDS-2102E 100MHz 2-channel desktop digital oscilloscope features a real-time sampling rate of 1GSa/s per channel, making it ideal for engineers and technicians conducting high-precision waveform analysis. With an 8-inch 800*480 TFT LCD display, it provides a clear view of complex waveforms and a minimum vertical sensitivity of 1mV/div. This oscilloscope supports various triggering methods and automatic measurement functions, enhancing work efficiency.
Specifications
- Bandwidth100MHz
- Channels2
- Sampling Rate8 Bit
- Memory Depth120,000 波形/每秒
- Resolution小於 3.5ns
- Waveform Update Rate最大 10Mpts
- Rise Time300Vrms, CAT I
- Timebase Accuracy± 3% full scale
- Input Impedance約 1MΩ// 16pF
- Overload Protection24 組
- Trigger Accuracy±3% full scale
- Vertical Sensitivity-
Features
- Wave Trigger正體中文／簡體中文／英文等
- Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/ Overshoot
- Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, – Width, Duty Cycle
- Multi-language InterfaceCH1, CH2, CH3*, CH4*, Line, EXT
- Search and Navigation6位數解析度，誤���±2％
- Signal OutputUSB 2.0, Ethernet(RJ-45), Go-NoGo BNC, Kensington Style Lock
Attributes
- Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
- Storage Temperature-20~60°C / Below 70%RH @35°C, no condensation
- Altitude LimitLower than 1,000 meters
- DisplayApprox. 18W, 40VA maximum
- Power Supply1A slow, 250V
- Fuse7“ TFT WVGA color display
- Interface384 X 208 X127.3 mm
- DimensionsApprox. 2800g
- WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
- Accessories示波器測棒x2、示波器測棒調整工具、傳輸線、光碟、說明書
