70MHz 2-channel Desktop Digital Oscilloscope
Brand
GWINSTEK
|
Model
GDS-2072A
■ 70 MHz bandwidth, 2/4 channel options
■ 2GSa/s real-time sample rate and 100GSa/s equivalent sample rate
■ 2M memory depth
■ Built-in waveform search and segmented memory functions
■ Up to 80,000 waveforms per second update rate
■ Standard UART, I2C, and SPI triggering and decoding
■ Optional 8 or 16 digital channels for mixed-signal oscilloscope upgrade
■ Digital channels include UART, I2C, and SPI serial and parallel bus triggering and decoding
■ Optional 5MHz and 25MHz signal generators
■ Flexible interface options (standard: USB; optional: LAN/GPIB)
■ Free upgrade for CAN/LIN bus analysis, advanced logic, data logger, digital voltmeter, and horizontal trigger point expansion
Out of Stock
Views: 50
Description
The GDS-2072A is a 70MHz 2-channel desktop digital oscilloscope that features a memory depth of up to 2M, providing precise measurement capabilities for high-frequency and weak signals. With a vertical sensitivity of 1mV/div and a time range from 1ns/div to 100s/div, users can accurately capture complex waveforms. The built-in waveform search and segmented memory functions enhance measurement flexibility and efficiency.
Specifications
- Bandwidth70MHz
- Channels2
- Sampling Rate8 Bit
- Memory Depth80,000 波形/每秒
- Resolution小於 5ns
- Waveform Update Rate最大 10Mpts
- Rise Time300Vrms, CAT I
- Timebase Accuracy± 3% full scale
- Input Impedance約 1MΩ// 16pF.
- Overload Protection24 組
- Trigger Accuracy±3% full scale
- Vertical Sensitivity-
Features
- Wave TriggerTraditional Chinese / Simplified Chinese / English
- Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/ Overshoot
- Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, – Width, Duty Cycle
- Multi-language InterfaceCH1, CH2, CH3*, CH4*, Line, EXT
- Signal OutputRS232, USB 2.0 , 網路(RJ-45), Go-NoGo BNC, Kensington Style Lock [選配 SVGA 影像埠]
Attributes
- Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
- Storage Temperature-20~60°C / Below 70%RH @35°C, no condensation
- Altitude LimitLower than 1,000 meters
- DisplayApprox. 18W, 40VA maximum
- Power Supply1A slow, 250V
- Fuse7“ TFT WVGA color display
- Interface384 X 208 X127.3 mm
- DimensionsApprox. 2800g
- WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
- Accessories示波器測棒x2、示波器測棒調整工具、傳輸線、光碟、說明書
