100MHz 2-channel Desktop Digital Oscilloscope
Brand
GWINSTEK
|
Model
GDS-1102B
|
🇹🇼 Taiwan
■ 1GSa/s sampling rate
■ Maximum 10M memory depth per channel
■ 7-inch 800 x 480 WVGA LCD display
■ 256-level display function to enhance waveform representation
■ 1Mpts FFT frequency domain signal display
■ One-touch zero setting
■ Innovative design, lightweight
Price
NT$ 19,215
Out of Stock
Views: 63
Description
The GDS-1102B 100MHz 2-channel desktop digital oscilloscope features optimized long memory and high-resolution display, allowing clear presentation of fine waveform variations to enhance analysis efficiency. With a sampling rate of up to 1GSa/s and a maximum memory depth of 10M per channel, it easily captures and analyzes complex signals. The 7-inch WVGA LCD screen, combined with a 256-level display feature, enriches waveform representation, making it suitable for a wide range of testing needs.
Specifications
- Bandwidth100MHz
- Channels2
- Sampling Rate8 Bit
- Memory Depth50,000 波形/每秒
- Resolution小於 3.5ns
- Waveform Update Rate最大 10Mpts
- Rise Time300V (DC+AC peak), CAT II
- Timebase Accuracy± 3% full scale
- Input Impedance1MΩ ±2%, ~15pF
- Overload Protection24 組
- Trigger Accuracy±3% full scale
- Vertical Sensitivity-
Features
- Wave Trigger正體中文／簡體中文／英文等
- Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/ Overshoot
- Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, – Width, Duty Cycle
- Multi-language InterfaceCH1, CH2, CH3*, CH4*, Line, EXT
- Search and Navigation6位數解析度，誤差±2％
- Signal OutputUSB 2.0 High-speed host, USB High-speed 2.0, RJ-45, Go-NoGo BNC
Attributes
- Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
- Storage Temperature-20~60°C / Below 70%RH @35°C, no condensation
- Altitude LimitLower than 1,000 meters
- DisplayApprox. 18W, 40VA maximum
- Power Supply1A slow, 250V
- Fuse7“ TFT WVGA color display
- Interface380 X 208 X 127.3 mm
- DimensionsApprox. 2800g
- WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
- Accessories示波器測棒x2、示波器測棒調整工具、傳輸線、光碟、說明書
